HP Series - High Pressure Humidifiers

Adiabatic Industrial Humidifier / Commercial Humidifier

Using advanced atomization nozzles to ensure efficient evaporation, the Condair high pressure HP-Series humidification system provides considerable operating cost savings when compared to other humidifier technologies.

Precision impeller type high pressure nozzles generate an extremely fine spray of water droplets. A unique nozzle manifold design ensures that the spray is uniform and
absorbed over a short distance. In combination with the Condair Mist Eliminator, the humidified air is 99% free of aerosols for hygenic operation.

High Precision Nozzles deliver 10-40 micron droplets through a 0.008" orifice. A single nozzle produces 12 lbs/hr of water without the need for compressed air. Constructed from durable stainless steel and factory assembled onto manifolds, Condair nozzles are easy to integrate into any project.

The Pump Module supplies high-pressure water to the patented nozzles eliminating the need for a compressed air system. Reverse Osmosis water is supplied to the pump system at 25-60 PSIG (172- 413 kPa) and exits the nozzles at 1000 PSIG (6895 kPa). Pumps are available in brass or stainless steel, and with or without a variable
frequency drive.

Why Choose the HP Series?

Modular design to fit many air handling unit (AHU) sizes.
Connect 1 HP pump to numerous AHU's saving on total costs.
Extremely low energy consumption when compared to steam humidifiers (save 90% of total energy).
Customizable solutions for true (n+l) redundancy, dual pump configuration, BAS/BMS communication, and large loads (over 9000 lbs/hr).
Integrated reverse osmosis (RO) water treatment.
Add-on options for ultra-hygienic and sensitive applications: Deionized (DI) water production and clean-in-place (CIP) intelligent water disinfection.
